Anycubic Photon Mono M7
Anycubic Photon Mono M7 Resin 3D Printer, 14K COB Source, 170mm/h Max Print Speed, 10.1inch Mono LCD, Dynamic Light-off, Leveling-free, 223*126*230mm
Highlights
Anycubic Photon M7
The Anycubic Photon Mono M7, equipped with the Light Turbo 3.0 light system and 14K COB light source, effortlessly transforms your concepts into reality with remarkable precision and impressive speed. Experience flawless prints, razor-sharp details, and smooth surfaces that will impress you!
- Light Turbo 3.0 lighting system
- 14K COB light source
- Automatic & precise free-leveling
- Intelligent assistance systems
Ultra Fast Speed
Anycubic Photon Mono M7 achieved a high speed of 170mm/h on a 0.1mm layer thickness test using high-speed resin. At the same time, the printing speed of standard resin has been increased to 130mm/h, breaking boundaries and greatly improving printing efficiency, achieving true fast speed printing
High-Precision 14K
With a 14K monochrome LCD screen with 13312*5120 resolution and 16.8×24.8 μm XY resolution, the Photon Mono M7 is capable of printing holes as small as 0.3 mm in diameter, which is more than enough to handle fine printing tasks and make your models stand out.
Advanced COB LighTurbo 3.0
The COB light source system, combined with Fresnel lenses and front-facing reflectors can reach the light angle within 3°, and light uniformity is more than 90%. Anycubic LighTurbo 3.0 is also equipped with a light-off compensation algorithm, which ensures that every layer of the model is successfully exposed and successfully removed from the mold, and improves the printing success rate.
Upgraded Assisted Features
Dynamic temperature control resin vat will adjust the temperature of the resin material to maintain the optimal print temperature at all times for print success. And resin auto-fill feature allows for automatic filling and one-key recycling of remaining resin
Intelligent Design
On the basis of component connection status detection, residue detection, resin level Detection, failed print detection, and release film lifespan management, Photon Mono M7 has added platform installation status detection. 6 types of intelligent detection can achieve startup detection, simplify printing process, and reduce problems caused by misoperation
Specification
| General | Brand: Anycubic Type: Resin 3D Printer Model: Photon Mono M7 Color: Black |
| Specification | Machine Leveling: Leveling-free Light Source: COB Light Source Printing Volume: 223*126*230mm Layer Height: ≥0.01mm Printing Speed: Standard Resin 0.1mm layer height: Max. 90mm/h High-Speed Resin 0.1mm layer height: Max. 150mm/h LCD Screen: 10.1″ Mono LCD LCD Resolution: 14K (13312 * 5120) Light Intensity: 4500±10%uW/cm2 Light Uniformity: ≥90% |
| Weight & Size | Product Weight: 8.2kg Package Weight: 9.2kg Product Size(L x W x H): 31×31.5x52cm Package Size(L x W x H): 62×39.5x39cm |
| Package Contents | 1 x Resin 3D Printer 1 x Print Platform 1 x Resin Vat 1 x User Manual 1 x Screen Protector Kit 1 x Leveling Paper 1 x Air Purifier 1 x Protective Equipment 5 x Funnels 2 x Scrappers 1 x Hex Key Set 1 x USB Drive 1 x WiFi Antenna 1 x Power Cord |
